细胞动态观察舱
时间：2016-10-04来源：本站作者：玉研仪器
详细介绍
细胞动态观察舱用于控制显微镜观察台的温度、湿度、气体浓度保持恒定的状态，以进行长时间动态细胞观察。
我们为各种品牌的显微镜定制专业的细胞观察舱。更多型号请来电咨询。
细胞动态观察舱h301-mini
stage compatibility:
h301-mini has the footprint of a multi well plate
fits in any stage equipped with mw holder
the chamber can fit:
35/60 mm petri
1x3 in. / 1x2 in. chambered slides
features:
magnets allow easy interchange chamber inserts
perfusion holes: 12 channels for 2.5mm o.d. tubings are available
h101-mini 细胞动态观察舱
stage compatibility: fits in any holder for mw plate and in physik instrumente pi p-737
h101-mini has the footprint of a multi well plate
fits in any stage equipped with mw holder
fits in physik instrumente p-737
the chamber can fit:
35/60 mm petri
1x3 in. / 1x2 in. chambered slides
features:
magnets allow easy interchange chamber inserts
perfusion holes: 12 channels for 2.5mm o.d. tubings are available
available inserts
|
h101-1x35-m single |
#1 35mm petri-dish |
|
1xgs-m-single |
#1 1x3in. chamberslide |
|
1xlabtek-m-single |
#1 lab-tek 1x2 in. chambered cover glass |
|
1xlabtek-ii-m-single |
#1 lab-tek ii 1x2 in. chambered cover glass |
|
1x60-m-single |
#1 60mm petri-dish |
h101-lg
stage compatibility: fits in the super z galvo stage (sp5/sp8), by replacing the leica specimen holder
features:the chamber hosts #1 35mm petri dishchamber uniformly heated by means water circulation in water tight channels present in the main body and in the lid.total weight on galvo stage: 131 gperfusion holes: 4 channels for 2.0 mm o.d. tubings are available for perfusion
water jacket chambers
the water jacket incubator provides superior incubation stability above and below room temperature. water is pumped from a water bath into the base plate and into the lid, which are both water jackets.temperature is measured inside a reference petri-dish and is controlled by circulating water from a water bath into the water jacket chamber. the temperature controller reads the temperature in the reference well and updates the set point temperature of the water bath, ensuring a specimen temperature stability of ± 0.1°c.
features
temperature range: from -5°c to 60°c
temperature accuracy: ± 0.1°c in sample feedback mode, ± 0.3°c in chamber feedback mode
water circulation in the bottom and lid of the chamber
inter changeable magnetic inserts allow to host petri, slides and mw plates
magnetic locks hold the petri, the slides and the mw plates in the correct position inside the chamber
perfusion holes for inlet and outlet of tubes
h301-k-frame
stage compatibility: fits in the following stages with 160x110 (k-frame) opening - comes with sliding lid
asi: all models, including z-piezo
leica: all models with 160x110 opening
ludl: all models with 160x110 opening
marzhauser: all models
olympus: all models with 160x110 opening
prior: h107
zeiss: all models with 160x110 opening
magnetic interchangeable inserts allow to use:
35/60 mm petri
1x3 in. / 1x2 in. chambered slides
6-12-24-48-96 mw plates (without addition of inserts)
available inserts
|
6mw |
6 well plates |
|
12mw |
12 well plates |
|
24mw |
24 well plates |
|
24mw-nunc |
24-well nunc/greiner plates |
|
48mw |
48-well plates |
|
96mw |
96-well plates. includes mw-oil |
|
mw-oil |
open frame to image multi well plates with oil immersion objectives |
|
1x35-m |
#1 35mm petri-dish |
|
1xgs-m |
#1 1x3in. chamberslide |
|
1xlabtek-m |
#1 lab-tek 1x2 in. chambered cover glass |
|
1xlabtek-ii-m |
#1 lab-tek ii 1x2 in. chambered cover glass |
|
1x60-m |
#1 60mm petri-dish |
|
1xt25-m |
#1 nunc and greiner t25 flask |
|
2x35-m |
#2 35mm petri-dish |
|
2xgs-m |
#2 1x3in. chamberslides |
|
2xlabtek-m |
#2 lab-tek 1x2 in. chambered cover glass |
|
2xlabtek-ii-m |
#2 lab-tek ii 1x2 in. chambered cover glass |
|
2x60-m |
#2 60mm petri-dish |
|
4x35-m |
#4 35mm petri-dish |
|
gs35-m |
#1 1x3in. chamberslide and #2 35mm petri-dish |
|
labtek-35-m |
#1 lab-tek 1x2 in. chambered cover glass and #2 35mm petri-dish |
|
labtek-ii-35-m |
#1 lab-tek ii 1x2 in. chambered cover glass and #2 35mm petri-dish |
|
labtek-60-m |
#1 lab-tek 1x2 in. chambered cover glass and #1 60mm petri-dish |
|
labtek-ii-60-m |
#1 lab-tek ii 1x2 in. chambered cover glass and #1 60mm petri-dish |
|
gs60-m |
#1 1x3in. chamberslide and #1 60mm petri-dish |
|
6035-m |
#1 60mm petri-dish and #1 35mm petri-dish |
available lids
|
h301-koehler lid |
glass lid that reduces the height of the chamber and allows to work under koehler illumination. minimum condenser working distance (without chamber riser): 22mm |
|
h301-injection-lid |
glass lid with two small openings (sealed with flexible plastic) to allow injection or permanent access to the specimen note: compatible only with specimen holder 1x35 |
|
h301-laser-interlock-lid |
glass lid with a safety switch that connects to the laser box. the switch turns off the laser, when the lid is lifted note: compatible only with specimen holder 1x35 |
h101-k-frame
stage compatibility: fits in the following stages with 160x110 (k-frame) opening
asi: all xy stages. not compatible with asi z-piezo
leica: all models with 160x110 opening
ludl: all models with 160x110 opening
marzhauser: all models
olympus: all models with 160x110 opening
prior: h107
zeiss: all models with 160x110 opening
magnetic interchangeable inserts allow to use:
35/60 mm petri
1x3 in. / 1x2 in. chambered slides
6-12-24-48-96 mw plates (without addition of inserts). one mw lock is required to hold the mw plate in the chamber
available inserts
|
mw-lock-22.5 |
magnetic lock to hold the standard mw plates in the chamber |
|
mw-lock-16.5 |
magnetic lock to hold the low-profile mw plates in the chamber |
|
h101-6mw |
6 well plates. one mw lock required |
|
h101-12mw |
12 well plates. one mw lock required |
|
h101-24mw |
24 well plates. one mw lock required |
|
h101-24mw-nunc |
24-well nunc/greiner plates. one mw lock required |
|
h101-48mw |
48-well plates. one mw lock required |
|
h101-96mw |
96-well plates. one mw lock required |
|
h101-1x35-m |
#1 35mm petri-dish |
|
h101-1xgs-m |
#1 1x3in. chamberslide |
|
h101-1xlabtek-m |
#1 lab-tek 1x2 in. chambered cover glass |
|
h101-1xlabtek-ii-m |
#1 lab-tek ii 1x2 in. chambered cover glass |
|
h101-1x60-m |
#1 60mm petri-dish |
|
h101-1xt25-m |
#1 nunc and greiner t25 flask |
|
h101-2x35-m |
#2 35mm petri-dish |
|
h101-2xgs-m |
#2 1x3in. chamberslides |
|
h101-2xlabtek-m |
#2 lab-tek 1x2 in. chambered cover glass |
|
h101-2xlabtek-ii-m |
#2 lab-tek ii 1x2 in. chambered cover glass |
|
h101-2x60-m |
#2 60mm petri-dish |
|
h101-4x35-m |
#4 35mm petri-dish |
|
h101-gs35-m |
#1 1x3in. chamberslide and #2 35mm petri-dish |
|
h101-labtek-35-m |
#1 lab-tek 1x2 in. chambered cover glass and #2 35mm petri-dish |
|
h101-labtek-ii-35-m |
#1 lab-tek ii 1x2 in. chambered cover glass and #2 35mm petri-dish |
|
h101-labtek-60-m |
#1 lab-tek 1x2 in. chambered cover glass and #1 60mm petri-dish |
|
h101-labtek-ii-60-m |
#1 lab-tek ii 1x2 in. chambered cover glass and #1 60mm petri-dish |
|
h101-gs60-m |
#1 1x3in. chamberslide and #1 60mm petri-dish |
|
h101-6035-m |
#1 60mm petri-dish and #1 35mm petri-dish |
